| Item | Nano core（black plastic case） | Model | 16*10*8 | ||||||||||
| Sampling inspection plan: product magnetic properties, shaking, weight, appearance are fully inspected according to the specifications | |||||||||||||
| Product inspection record (record 10PCS) | |||||||||||||
| Test items | Inductance test | Core weight（g） | Appearance | Sloshing test | |||||||||
| Test Conditions | 10KHz 100mV | ||||||||||||
| Measurement standard | AL＞30µH | ||||||||||||
| 1 | 46.65 | 4.07 | OK | OK | |||||||||
| 2 | 51.88 | 4.05 | OK | OK | |||||||||
| 3 | 50.54 | 4.10 | OK | OK | |||||||||
| 4 | 50.84 | 4.00 | OK | OK | |||||||||
| 5 | 45.47 | 4.15 | OK | OK | |||||||||
| 6 | 52.92 | 4.12 | OK | OK | |||||||||
| 7 | 47.49 | 4.29 | OK | OK | |||||||||
| 8 | 50.46 | 3.92 | OK | OK | |||||||||
| 9 | 48.49 | 4.06 | OK | OK | |||||||||
| 10 | 50.62 | 4.17 | OK | OK | |||||||||
| Product appearance size inspection (1PCS) | |||||||||||||
| Item | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | |||
| ID Size mm | 8.53 | ||||||||||||
| OD Size mm | 17.74 | ||||||||||||
| Height mm | 9.69 | ||||||||||||
| Item | Packing list | Inspection list | ROHS | Apprance | Quantity check | ||||||||
| Determination | OK | OK | OK | OK | OK | ||||||||
| Shipper | LZZ | Inspector | HXH | Audit | LY | ||||||||
